BELLTECH COILOVER KIT 2002-2009 Chevrolet Trailblazer, 04-09 Trailblazer SS 0"-3" Drop (Stainless Steel, Adj. Rebound & Compression)

Fits:
2003-2006 Chevrolet SSR ; 1" to 2" F / 2" R
2002-2009 GM Trailblazer, Envoy ; 1" to 2.5" F / 3" R
2006-2009 GM Trailblazer SS ; 0" to 1.25" F

Unlock the potential suspension performance in your GM SSR, Trailblazer, or Envoy with the Belltech V3 coilover kit.

Our premium engineered coilover kit includes finely tuned Belltech threaded front dampers. The dampers feature a large 50mm damper body and independent rebound and compression valves. Together, these details keep oil cool and deliver precise, consistent damping throughout suspension travel. We feature linear, cold-formed tensile steel springs, and powder-coat them to prevent rust and wear. We add a progressive rate polymer, open-cell, bump stop for precise bump stop engagement. Belltech GM coilovers are designed to use the OEM top mounts for simplified installation.

The rear ride height is lowered with Belltech progressive springs and a composite spring spacer to choose between two height settings. We feature two vehicle-specific, precisely tuned, damping adjustable shocks. Our shock methodology is known to produce an exceedingly smooth ride, reducing the harshness of flawed roads.

• Lowering Range: Application specific (see above)
• Front height adjustable V3 coilovers and rear V3 Performance shocks
• Large 50mm stainless strut housings
• 18mm hardened chrome piston rods
• Rear cold-formed steel lowering springs
• Rear 1” spring spacers for height adjustability
• Progressive rate polymer, open cell, bump stops
• Sport tuned spring rates
• OEM quality damper components for added durability
• Engineered to exemplify ride quality and performance

IMPORTANT NOTES:

• For models with rear air suspension, the air springs must be removed, and the air system must be disabled.
